Intelligent Fertigation System two

Five Major Advantages

1.Integrating fertilization and control into one unit.

Integrating fertilization and control into one system, it not only controls the operation of the fertilizer suction channel and injection pump but also regulates the operation of external electromagnetic valves. Furthermore, it can control a main valve or water pump, effectively meeting the diverse requirements of users.

2.Remote Control

The control system features both manual and automatic control modes, allowing users to switch between them conveniently. Optional mobile remote connection control is available, compatible with both Android and iOS systems.

3.Strong Fertilizer Suction Capability

The fertilizer suction channels are equipped with the Da Feng Shou irrigation venturi fertilizer injector, with a maximum capacity of 8 units, and 3 channels provided as standard. Each individual suction channel allows adjustable fertilizer intake ranging from 25 L/h to a maximum of 1000 L/h. EC and pH meters enable real-time monitoring of the EC and pH values of the applied fertilizers, displaying the readings on the EC and pH meter for user convenience. This allows users to adjust the fertilizer application rate in real-time according to their needs and regulate the fertilizer intake by controlling the valves on the fertilizer suction channels.

4.Visual Touch Screen

Industrial-grade LCD Touch Screen is utilized, facilitating on-site observation, operation, and usage for users.

5.Technical Assurance

The system is equipped with water pressure detection and alarm functions; in case of abnormal equipment operation, it can automatically halt. Rich historical records and data curves can be stored and exported using commonly used SD cards or USB drives, with optional remote control for remote viewing.
